FARMTRAC HIGHLIGHTS
DUAL CLUTCH
POWER STEERING
ADJUSTABLE AXLE
1800 KG CAPACITY
TOUGHEST TYRE
1850 RPM
PRODUCT SPECIFICATION
|
ENGINE |
|
|
No of Cylinders |
3 |
|
Power at Rated ERPM (HP) |
48 HP |
|
Rated ERPM |
1850 |
|
TRANSMISSION |
|
|
Gear Box Type |
8F+2R Full Constant Mesh |
|
Location of Gear Shifting |
Side Shift |
|
Rear Axle Type |
EPI |
|
CLUTCH |
|
|
Type |
Dual Clutch |
|
ROAD SPEEDS |
|
|
Forward Road Speed @ Rated ERPM |
2.7-30.6 Kmph |
|
Reverse @ Rated ERPM |
3.0-10.9 Kmph |
|
BRAKES |
|
|
Type |
Multi Plate Oil Immersed Brakes |
|
HYDRAULICS |
|
|
Type & Lift Capacity [Horizontal
position] |
ADDC – 1800 kg |
|
Spool Valve |
1 Double Acting Directional Control Valve |
|
STEERING |
|
|
Type |
Balanced Power Steering |
|
POWER TAKE OFF |
|
|
PTO Type |
540 Single and Multi Speed Reverse PTO |
|
540 PTO at Engine RPM |
1810 |
|
TYRE SIZES |
|
|
Front |
6.5×16 |
|
Rear |
14.9X 28 |
|
FRONT AXLE |
|
|
Type |
Adjustable Axle |
|
FUEL TANK CAPACITY |
|
|
Litres |
60 |
|
WEIGHT & DIMENSIONS |
|
|
Total Weight, kg |
2245(Unballasted) |
|
Wheelbase (mm) |
2145 |
|
Turning Radius (mm) |
3250 |
|
Overall Length (mm) |
3485 |
|
Overall Width (mm) |
1810 |
|
Ground Clearance (mm) |
377 (below transmission housing) |
